Image Sensor Size18.96 x 10 mm (4/3")Sensor TypeCMOSShutter TypeRolling ShutterISO100 to 25,600 (Expanded)Advertised Dynamic Range13 Stops
Camera
Lens MountMicro Four ThirdsLens CommunicationYesBuilt-In ND FilterNoneBuilt-In Microphone TypeStereoRecording Media1 x CFast 2.0 Card Slot
1 x SDXC UHS-II Card Slot
INTERNAL RECORDING
Raw RecordingRaw: 4096 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (21 to 203 MB/s) Recording ModesProRes 422HQ: 4096 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (117.88 MB/s) 3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (110 Mb/s)
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60/120 fps (27.5 MB/s)
ProRes 422: 4096 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (78.63 MB/s) 3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (73.6 MB/s)
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60/120 fps (18.4 MB/s)
ProRes 422LT: 4096 x 2160p at 23.98/24/25/29.97/30/50/59.94/60 fps (54.63 MB/s) 3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (51 MB/s)
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60/120 fps (12.75 MB/s)
ProRes 422 Proxy: 4096 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (24.25 MB/s) 3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (22.4 MB/s)
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60/120 fps (5.6 MB/s)
EXTERNAL RECORDING
Video Output
4:2:2 10-Bit via HDMI: 1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
Raw Output USB:
4096 x 2160 12-Bit at 23.98/24/25/29.97/30/50/59.94/60 fps 3840 x 2160 12-Bit at 23.98/24/25/29.97/30/50/59.94/60 fps
1920 x 1080 12-Bit at 23.98/24/25/29.97/30/50/59.94/60 fps
INTERFACES
Video Connectors
1 x HDMI OutputAudio Connectors
1 x Mini XLR Mic/Line Level (+48 V Phantom Power) Input
1 x 1/8" / 3.5 mm Stereo Mic/Line Level Input
1 x 1/8" / 3.5 mm Stereo Headphone OutputOther I/O
1 x USB Type-C Video Output
1 x 3.5 mm Timecode Input (Shared with 3.5 mm Mic/Line input)
Wireless InterfacesBluetooth Control
DISPLAY
Display TypeLCDScreen Size5"TouchscreenYesScreen Resolution1920 x 1080
POWER
Battery TypeCanon LP-E6
POWER CONNECTORS
1 x Weipu SF610/S2 Input
ENVIRONMENTAL
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 113°F / -20 to 45°C
Operating Humidity 0 to 90%
GENERAL
Accessory Mount1 x 1/4"-20
FemaleTripod Mounting Thread1/4"-20
FemaleMaterial of ConstructionCarbon Fiber
Dimensions 7 x 3.8 x 3.4" / 177.8 x 96.52 x 86.36 mmWeight1.5 lb / 680.38 g
